Wagner Tuning Audi S4 B9/S5 F5 Intercooler Bundle

Description

Wagner Tuning Audi S4 B9 / S5 F5 Intercooler Bundle

The Wagner Tuning Competition Intercooler Bundle is a direct upgrade for the Audi S4 B9 and S5 F5 3.0 TFSI, replacing the restrictive factory unit with a much larger, more efficient core and complete charge pipe kit. Designed to keep intake temperatures lower under sustained load, it helps the 3.0 TFSI engine maintain consistent power, especially during spirited driving, track use, or when running tuned software.

This bundle version includes the upgraded charge air piping, giving you a full air-side upgrade in one go: cooler, denser air into the engine and stronger, more durable hose connections.

What it does and why it matters

An intercooler cools the compressed air from the turbocharger before it enters the engine. Cooler air is denser, which means more oxygen and a more efficient burn. The factory intercooler on the B9/F5 platform is known to heat soak quickly under hard use, causing the ECU to pull timing and reduce boost to protect the engine. The Wagner core has far greater volume and frontal area, so it stays cooler for longer and recovers temperature faster between pulls.

• 134% larger flow area and 105% more charge air volume compared to the OEM intercooler
• Tube Fin core with internal turbulators for efficient heat transfer
• Cast aluminium end tanks, CFD-developed for low pressure drop
• Anti-corrosion coating that also aids heat dissipation
• Pressure tested up to 6 bar, suitable for road and racing use
• Lightweight at just 9.5 kg despite the increased size
• Direct fit replacement, no cutting or modification required

Charge Pipe Upgrade Included

This bundle adds a black-coated aluminium charge pipe and three reinforced silicone hoses. The factory plastic pipework is a known weak point under increased boost and can split or pop off when pushed. The aluminium pipe and uprated silicone connections give you a stronger, more reliable air path that can handle higher boost pressures from tuning.

Core Specifications

Kit Contents

• 1 x Competition Intercooler (black coated)
• 1 x Aluminium charge pipe (black coated)
• 3 x Reinforced silicone hoses (black)
• Mounting hardware
• Installation instructions

Vehicle Fitment

Designed for the 3.0 TFSI engine fitted to:

• Audi S4 B9 3.0 TFSI 260kW / 354PS (2016 onwards)
• Audi S5 F5 3.0 TFSI 260kW / 354PS (2016 onwards)

Important: The supplied mounting brackets are only suitable for EU specification models. Please use the vehicle lookup tool or check the Vehicle Fitment tab to confirm compatibility before ordering.

Part Number: 200001120.PIPE
